AMVT-1 Automated Vacuum Leak Tester

Click for full sized image

Comply with the requirements of FDA – CFR 21-11
AT2E’s AMVT-1 Automatic Vacuum Leak Tester is an equipment specially designed for testing the sealing performance of containers such as vials, bottles, caps and cans made of glass, plastic, aluminum or other metal materials. Its stainless-steel frame design meets the standards for industrial applications.

The instrument is shipped with software included, with a user-friendly operation interface design, real-time display of measurement data curve during the measurement process, allowing a more intuitively and simply operation process.

Measuring principle:
AMVT-1 Automatic Vacuum Leak Tester tests the sealing performance of samples checking the vacuum difference.

  • The sample will be placed in the test chamber, then the instrument generates the vacuum to make the test chamber reach a target vacuum level and hold it for a predefined period.
  • The vacuum difference in the test chamber will be monitored during the holding process.
  • The maximum vacuum difference will be compared with the set threshold, then the sealing performance of the sample under vacuum condition will be judged automatically.

Technical specifications:

  • Sample types: Vials, Bottles, Caps and Cans
  • Sample material: glass, plastic, aluminum or other metal materials
  • Sample capacity: 2 – 50 ml (standard model, other ranges under request)
  • Adjustable vacuum level:
    • With internal vacuum pump: up to – 900 mbar.
    • With external vacuum pump: up to – 999 mbar (according to the pump capacity)
  • Automatic adjustment of vacuum level and test time
  • Testing sensitivity: 2ml, leakage hole diameter ≥ 5μm
  • Auto leakage detection
  • Test chamber size: customizable according to sample
  • Dynamic display: test status, date, time
  • Display: Cycle settings, batch number, sample number, test result
  • Easy to operate, operator can select the preset test parameters and press the test button to carry out the test, no need to set the parameters every time
  • Product batch number editable
  • Connect to the software, print out test data

Mechanical specifications

  • Stainless steel frame
  • Dimensions: 15.8” x 14.6” x 15” / 400 x 370 x 382 mm (L x W x H)
  • Weight: 55 lbs / 25 kg
