The AT2E CO2-DA Automatic Shaker & CO2 Calculator is an essential tool for measuring carbon dioxide content in beverages packaged in glass or PET bottles and cans. Its easy operation and high repeatability make it indispensable for quality control in the beverage industry.

Key Features and Applications

• Accurate CO2 Measurement: The CO2-DA automatically shakes the sample and calculates the CO2 content with high precision and repeatability. This ensures consistent carbonation levels in beverages, which is crucial for maintaining product quality.
• User-Friendly Operation: The device is simple to use—just place the beverage sample, pierce the container, and press start. The motorized shaking system guarantees reproducible results, outperforming manual methods.
• Durable and Versatile Design: Constructed with stainless steel and featuring a high-resolution touchscreen interface, the device is both durable and easy to operate. It supports various container sizes and allows for customizable shaking speeds and durations.

Technical Specifications Summary

• CO2 Measuring Range: 0 – 9.99 g/l, with a precision of ±0.01 g/l
• Temperature Monitoring: 0 – 60 °C / 0 – 140 °F
• Pressure Range: 0 – 6 bar / 0 – 85 psi
• Sample Size: Up to 120 mm in diameter, 380 mm in height
• Power Supply: Available in 110V or 220V options
• Optional Enhancements: Mini Printer, QUALICO2 software, Full Safety Cover

FAQ for CO2-DA Automatic Shaker and CO2 Calculator

What is the CO2-DA Automatic Shaker and CO2 Calculator used for?

The CO2-DA is designed for accurately measuring the carbon dioxide content in beverages packaged in glass or PET bottles and cans. It plays a critical role in quality control within the beverage industry, ensuring consistent carbonation levels.

How does the CO2-DA ensure accurate CO2 measurements?

The CO2-DA features an automatic shaking mechanism that prepares the beverage sample for measurement. It calculates the CO2 content with high precision and repeatability, outperforming traditional manual methods and providing reliable results.

What are the technical specifications of the CO2-DA?

The CO2-DA has a CO2 measuring range of 0 – 9.99 g/l with a precision of ±0.01 g/l. It operates within a temperature range of 0 – 60 °C (0 – 140 °F) and a pressure range of 0 – 6 bar (0 – 85 psi). It can accommodate sample sizes up to 120 mm in diameter and 380 mm in height.

Is the CO2-DA easy to operate?

Yes, the CO2-DA is designed for user-friendly operation. Users simply place the beverage sample, pierce the container, and press start. The motorized shaking system ensures reproducible results without the need for manual intervention.

What optional enhancements are available for the CO2-DA?

Optional enhancements for the CO2-DA include a Mini Printer for immediate results, QUALICO2 software for data analysis, and a Full Safety Cover for added protection during operation.

What power supply options are available for the CO2-DA?

The CO2-DA is available in both 110V and 220V power supply options, making it versatile for use in different regions and settings.
