The AT2E APCC-1 is a laboratory instrument designed for the efficient and precise capping of pull-off caps on glass bottles with a crown finish. This device is ideal for preparing samples for quality inspections or related tests, often used in conjunction with AT2E’s POT-1 or POT-AUTO test machines.

Attributes & Benefits:

• Adjustable Compression Force: Allows customization of compression force from 1000 N to 4500 N (224.8 to 1011.6 lbf) to meet various test requirements.
• User-Friendly Operation: Features a touch screen control with one-key automatic capping for easy operation.
• Integration Capability: The capping head used in production lines can be integrated into this device (capping head to be supplied by the customer).
• Durable Construction: Built with a stainless steel frame for durability and long-term use.
• Compact Design: The desktop design makes it small and convenient for laboratory use.

Technical Specifications:

• Compression Range: 1000 N to 4500 N (224.8 to 1011.6 lbf)
• Accuracy: ±0.5% F.S.
• Sample Range:
  • Maximum height: 295 mm (11.6 in)
  • Maximum diameter: 85 mm (3.35 in) (Customized spacers required based on bottle diameter)
• Air Supply: 5 – 8 bar (72.5 – 116 psi)
• Power Supply: 220V AC / 50 Hz (optional 110V AC / 60 Hz)
• Overall Size: 400 x 445 x 1120 mm (15.75 x 17.5 x 44.1 in)
• Weight: 70 kg (154.3 lbs)

This instrument provides a reliable and efficient solution for laboratory testing, ensuring that your samples are consistently and accurately capped for further testing.

FAQ for APCC-1 Automated Pull-off Cap Capper

What is the APCC-1 Automated Pull-off Cap Capper used for?

The APCC-1 is designed for the precise and efficient capping of pull-off caps on glass bottles with a crown finish. It is commonly used in laboratories to prepare samples for quality inspections and various tests.

What are the adjustable features of the APCC-1 Cap Capper?

This device features an adjustable compression force ranging from 1000 N to 4500 N (224.8 to 1011.6 lbf), allowing users to customize the capping force according to specific test requirements.

How does the touch screen control work on the APCC-1?

The APCC-1 is equipped with a user-friendly touch screen control that enables one-key automatic capping. This simplifies the operation, making it easy for users to cap bottles efficiently.

Can the APCC-1 be integrated with other equipment?

Yes, the APCC-1 can be integrated with capping heads used in production lines. However, the capping head must be supplied by the customer to ensure compatibility.

What are the technical specifications of the APCC-1?

The APCC-1 has a compression accuracy of ±0.5% F.S., supports a maximum bottle height of 295 mm (11.6 in) and a maximum diameter of 85 mm (3.35 in), requires an air supply of 5 – 8 bar (72.5 – 116 psi), and operates on a power supply of 220V AC / 50 Hz (with an optional 110V AC / 60 Hz). Its overall dimensions are 400 x 445 x 1120 mm (15.75 x 17.5 x 44.1 in) and it weighs 70 kg (154.3 lbs).

What materials are used in the construction of the APCC-1?

The APCC-1 is constructed with a durable stainless steel frame, ensuring long-term use and reliability in laboratory settings.
