CEBT-1 – Can and End Buckle Tester

The CEBT-1 is designed to test the buckle strength of beverage cans and can ends. It accurately measures the pressure at which cans or ends buckle, ensuring they meet industry standards for durability and safety.

Product Overview

Our advanced design allows for seamless testing of both necked-in and straight-wall cans without the need to change clamps. The user-friendly interface simplifies operation and maintenance.

Key Features:

• Optimal Design for Ease of Use: Streamlined operation with a PLC integrated system and touch screen control.
• Versatile Clamping: No need to change clamps when testing different types of cans.
• Adjustable Pressurization: Set different target pressures in steps, with adjustable pressurization speed.
• External Pneumatic Boosters (Optional): Two booster options available, capable of increasing inlet pressure by 2x or 4x.
• Robust Construction: Stainless steel frame ensures durability and strength.
• Safety and Protection: Equipped with overload protection and various safety features.
• Comprehensive Data Display: View test results directly on the screen, with the ability to review previous results and automatically calculate average, maximum, and minimum values.
• RS232C Data Output: Facilitates easy data transfer.
• Calibration Interface: Simplifies the calibration process.

Technical Specifications:

• Sample Compatibility: Suitable for beverage cans and can ends.
• Measurement Range: 0-9 bar (0-130 psi) with a resolution of 0.01 bar (0.15 psi).
• Data Output: RS232C
• Power Supply: 120V/60Hz or 230V/50Hz
• Air Supply: 5 – 8 bar (72.5 – 116 psi)
• Dimensions: 30” x 18” x 38” (750 x 450 x 950 mm)
• Weight: 200 lbs (90 kg)

Optional Add-ons:

• Additional End Assembly: For testing other sizes.
• Additional Pneumatic Boosters:
  • Option 1: Increases line pressure by 2x.
  • Option 2: Increases line pressure by 4x.

FAQ for CEBT-1 – Can and End Buckle Tester

What is the purpose of the CEBT-1 Can and End Buckle Tester?

The CEBT-1 is designed to measure the buckle strength of beverage cans and can ends, ensuring they meet industry standards for durability and safety. It accurately determines the pressure at which the cans or ends buckle, which is crucial for quality control in beverage packaging.

How does the CEBT-1 simplify the testing process?

The CEBT-1 features a user-friendly interface with a PLC integrated system and touch screen control, allowing for streamlined operation. Additionally, its versatile clamping design eliminates the need to change clamps when testing different types of cans, making it efficient and easy to use.

What are the key specifications of the CEBT-1?

The CEBT-1 has a measurement range of 0-9 bar (0-130 psi) with a resolution of 0.01 bar (0.15 psi). It is compatible with beverage cans and can ends, operates on a power supply of 120V/60Hz or 230V/50Hz, and requires an air supply of 5 – 8 bar (72.5 – 116 psi). Its dimensions are 30” x 18” x 38” (750 x 450 x 950 mm) and it weighs 200 lbs (90 kg).

Can the CEBT-1 store and display test results?

Yes, the CEBT-1 has a comprehensive data display that allows users to view test results directly on the screen. It can also review previous results and automatically calculate average, maximum, and minimum values for better analysis.

What optional features are available for the CEBT-1?

Optional add-ons for the CEBT-1 include an additional end assembly for testing other sizes and external pneumatic boosters that can increase inlet pressure by either 2x or 4x, enhancing the testing capabilities of the device.

How is the CEBT-1 constructed for durability?

The CEBT-1 is built with a robust stainless steel frame, ensuring durability and strength for long-term use. It is also equipped with overload protection and various safety features to enhance user safety during operation.
