for measuring the seam length (height) of a can
Ensure precise and reliable seam length measurements for cans with the SLG-1 Can Seam Length Gauge.
SLG-1 Seam Length Gauge is used for quickly obtaining a fast and accurate measurement of the seam length (Seam height).
The SLG-1 Can Seam Length Gauge provides fast and accurate measurements of the seam length (height) of cans. This reliable tool ensures consistent measuring pressure and angle, enhancing the precision of the results.
Accurate Measurements
The SLG-1 measures seam lengths with a range of 0-7 mm and a resolution of 0.01 mm, ensuring high accuracy and reproducibility. Its compact design makes it suitable for various can types, including 2-piece and 3-piece cans.
User-Friendly Design
The gauge features a user-friendly interface that allows operators to connect it to an SPC system or AT2E’s SeamCheck software via the DTB-1 Data Transporting Box, minimizing manual recording errors.
Versatile Application
Applicable to different can types, the SLG-1 is an essential tool for quality control in can manufacturing, ensuring accurate and reliable seam length measurements.
The SLG-1 Can Seam Length Gauge is crucial for maintaining high standards in can manufacturing, offering precise and efficient seam length measurements.
Designed for reliability, it offers an invariable measuring pressure and measuring angle which enables the operator to perform the measurement accurately. If the can body is aligned vertically, measurement results are more reliable. The SLG-1 is applicable for different types of cans.
In order to avoid the manual recording error, the gauge can be connected to SPC system or AT2E “SeamCheck” software with DTB-1 Data Transporting Box and cable. The data can then be transferred to SPC system or “SeamCheck” software through DTB-1 and cable.
| Technical specifications: | |
|---|---|
| Measuring range | 0-7 mm |
| Resolution | 0.01 mm |
| Accuracy | ±0.01 mm |
| Sample range | 2-pcs & 3-pcs can |
| Overall size | 300(L) x 80(W) x 265(H) mm |
| Net weight | 1 kg |
