SSA-AUTO Secure Seal Analyzer: Reliable Automated Leak Testing for Bottles and Cans

The SSA-AUTO Secure Seal Analyzer is an advanced, automated device designed for precise leak testing in bottles and cans. It offers customizable testing parameters, robust safety features, and seamless data management, making it an ideal solution for ensuring seal integrity in various containers.

Customizable Testing Features

The SSA-AUTO allows for adjustable pressure levels, pressurizing rates, and holding times, making it adaptable to diverse testing requirements. It can handle samples up to 350 mm in height and 120 mm in diameter, making it versatile for a wide range of container sizes.

Enhanced Safety and Durability

Built from durable stainless steel, the SSA-AUTO is designed to be explosion-resistant, ensuring operator safety during testing. The intuitive touchscreen interface allows for easy operation and provides real-time visual feedback for detailed analysis.

Advanced Data Management

The SSA-AUTO can store up to 30 product profiles and 10 operator profiles, each protected by passwords for enhanced security. It supports data export via RS232, allowing for seamless integration with analytical software for comprehensive data review.

Key Features of the SSA-AUTO:

• Measuring range: 0 to 16.00 bar; Units: bar & psi; Resolution: 0.01 bar
• Comprehensive testing for bottles, cans, and preforms
• Exclusive AT2E special needle for precise and secure testing
• Accommodates samples up to 350 mm in height and 120 mm in diameter, with customizable neck diameters between 26-35 mm
• Explosion-resistant design with stainless steel construction
• Flexible testing settings with up to 4 stages for pressure, pressurizing rate, and holding time
• Detailed testing curve review for thorough analysis
• Capacity to store up to 30 product profiles and 10 operator profiles, with password protection
• Dynamic display options including statistics, hour, date, product name, operator, batch number, and sample number
• RS232 output for easy software integration
• Sturdy design with dimensions of 610 (L) x 500 (W) x 1040 (H) mm and a net weight of 60 kg

Optional Parts for Enhanced Functionality:

• “QUALIPRESS” software for advanced data analysis
• Water Recycling System for eco-friendly operation

FAQ for Secure Seal Analyzer (Automated Model) – SSA-AUTO

What is the purpose of the SSA-AUTO Secure Seal Analyzer?

The SSA-AUTO Secure Seal Analyzer is designed for precise leak testing in bottles and cans. It ensures seal integrity by allowing customizable testing parameters, making it suitable for various industrial applications.

What are the key features of the SSA-AUTO?

The SSA-AUTO features adjustable pressure levels, pressurizing rates, and holding times, accommodating samples up to 350 mm in height and 120 mm in diameter. It also includes an explosion-resistant design, stainless steel construction, and an intuitive touchscreen interface for easy operation.

How does the data management work with the SSA-AUTO?

The SSA-AUTO can store up to 30 product profiles and 10 operator profiles, each secured with passwords. It supports data export via RS232, allowing seamless integration with analytical software for comprehensive data review and management.

What is the maximum pressure range that the SSA-AUTO can test?

The SSA-AUTO has a measuring range of 0 to 16.00 bar, with a resolution of 0.01 bar. This allows for precise testing of various container types under different pressure conditions.

What optional accessories are available for the SSA-AUTO?

Optional accessories include the “QUALIPRESS” software for advanced data analysis and a Water Recycling System for eco-friendly operation, enhancing the functionality of the SSA-AUTO.

Is the SSA-AUTO safe to use in industrial settings?

Yes, the SSA-AUTO is built with robust safety features, including an explosion-resistant design and durable stainless steel construction, ensuring reliable and secure operation in various industrial environments.
