UBPT-1/1S – Universal Bottle Perpendicularity Tester

pixel

Click for full sized image

The UBPT-1/1S Universal Bottle Perpendicularity Tester accurately measures bottle perpendicularity using a specialized clamp rotary system, making it essential for quality control in the packaging and beverage industries. Its versatile design accommodates various bottle shapes and sizes, ensuring precise and reliable results.

SKU UBPT-1-1S-UNIVERSAL-BOTTLE-TESTER Categories , ,

The UBPT-1/1S Universal Bottle Perpendicularity Tester is a precision instrument designed to measure the perpendicularity (deviation) of bottles, making it indispensable for the packaging and beverage industries. Its innovative clamp rotary system allows it to measure any symmetrical bottle, enhancing quality control across various bottle shapes and sizes.

Efficient Testing System

Designed for user convenience, the UBPT-1/1S enables quick and accurate measurements of perpendicularity deviation. Its wide sample range accommodates different bottle sizes, ensuring versatility and reliability in testing.

Advanced Features

The UBPT-1/1S offers optional automatic calculators for easy reading and recording of MAX, MIN, and SAD (Sum of Absolute Differences between MAX and MIN) values. This feature simplifies the testing process while ensuring precise and consistent results.

Robust and Reliable

Built with durable materials, the UBPT-1/1S is designed for longevity and high performance. Its high-resolution measurement capability ensures even the smallest deviations are detected, maintaining stringent quality standards in production.

Optional parts:

An automatic calculator (sold separately or integrated into certain models) allows for easy data transmission and displays MAX, MIN, and SAD values, simplifying operator tasks and ensuring accuracy.

Technical specifications:

  • Sample Range: 50 – 120 mm in diameter (larger sizes available upon request)
  • Height Range: 110 – 350 mm (larger sizes available upon request)
  • Measuring Range: 0 – 10 mm
  • Resolution: 0.01 mm
  • Dimensions: 355 (L) x 250 (W) x 515 (H) mm
  • Net Weight: 20 kg

FAQ for UBPT-1/1S Universal Bottle Perpendicularity Tester

What is the purpose of the UBPT-1/1S Universal Bottle Perpendicularity Tester?

The UBPT-1/1S Universal Bottle Perpendicularity Tester is designed to measure the perpendicularity deviation of bottles. This is crucial for quality control in the packaging and beverage industries, ensuring that bottles meet strict quality standards.

What types of bottles can the UBPT-1/1S accommodate?

The UBPT-1/1S can accommodate a wide range of symmetrical bottle shapes and sizes, with a sample range of 50 – 120 mm in diameter and a height range of 110 – 350 mm. Larger sizes are available upon request, providing versatility for various testing requirements.

How does the UBPT-1/1S ensure accurate measurements?

The tester features a specialized clamp rotary system that enhances measurement accuracy. It has a high-resolution capability with a measuring range of 0 – 10 mm and a resolution of 0.01 mm, allowing it to detect even the smallest deviations in bottle perpendicularity.

Are there any optional features available with the UBPT-1/1S?

Yes, the UBPT-1/1S offers optional automatic calculators that can be integrated or sold separately. These calculators simplify the testing process by displaying and recording MAX, MIN, and SAD (Sum of Absolute Differences) values, enhancing the efficiency of data management.

What are the dimensions and weight of the UBPT-1/1S?

The UBPT-1/1S has dimensions of 355 mm (length) x 250 mm (width) x 515 mm (height) and weighs 20 kg. Its robust design ensures durability and reliability in various testing environments.

How does the UBPT-1/1S contribute to quality control in production?

By accurately measuring bottle perpendicularity, the UBPT-1/1S helps maintain stringent quality standards in production. Its ability to detect even minor deviations ensures that bottles meet the required specifications, reducing the risk of defects and enhancing overall product quality.

UBPT-1/1S – Universal Bottle Perpendicularity Tester

The UBPT-1/1S Universal Bottle Perpendicularity Tester accurately measures bottle perpendicularity using a specialized clamp rotary system, making it essential for quality control in the packaging and beverage industries. Its versatile design accommodates various bottle shapes and sizes, ensuring precise and reliable results.

SKU UBPT-1-1S-UNIVERSAL-BOTTLE-TESTER Categories , ,
