GBIT Glass Bottle Impact Tester for Accurate Resistance Testing

The GBIT Glass Bottle Impact Tester is essential for evaluating the impact resistance of glass bottles and jars. Utilizing a pendulum strike, it ensures precise, force-consistent impacts for reliable testing.

### High Precision Measurement
Built on the conservation of energy principles, this tester provides accurate measurements of impact resistance, ensuring the quality and durability of glass containers.

### User-Friendly Operation
With a flexible sample clamp and stainless steel safety shield, it offers ease of use and safety during testing.

### Versatile Applications
Ideal for various glass bottle sizes, it supports a wide range of testing needs in the packaging industry.

Attributes

  • The sample clamp is able to move flexibly in both vertical and horizontal directions, convenient for adjusting the sample’s position.
  • The instrument is designed according to the law of the conservation of energy, ensuring high testing accuracy and reliability.
  • A stable and accurate pendulum able to rotate and release freely.
  • Includes a stainless steel safety shield.
  • User-friendly design for simple operation.
Principle
Based on the law of conservation of energy, the energy when the pendulum impacts the bottle is determined by its potential energy of where it was hung. When the pendulum is hung at a certain angle, its potential energy is corresponds to particular value, and the impact energy on the bottle does too. By using the conversion relationship of the pendulum’s hanging angle and its impact energy of pre-defined energy values, we can release it and observe whether the bottle was damaged or not.

Technical Specifications
Sample diameter rangeФ20 -130 mm (clamps for other ranges available)
Max. impact energy2J
Resolution0.1J for each lattice (when impact energy larger than 0.6J)
0.05J for each lattice (when impact energy less than 0.6J)
Energy loss≤1.5%FS
Dimensions530 mm *350 mm *700 mm
